100 Watt 6 Bands High Power Outdoor waterproof Prison Jammer ,Mobile Phone 2G 3G 4G GPS WIFI Jammer Up to 150m

Item No.: 1506DW
Outdoor High power mobile phone signal jammers 6-Band for Prison project, output power 100W jamming up 150m is able to disable all mobile phone frequencies CDMA GSM, 2G, 3G, 4G Lte, 4G Winamx ,Also is middle RF power drone jammer model, can defend 100% dr
Description
Product description:
Outdoor High power mobile phone signal jammers 6-Band for Prison project, output power 100W jamming up 150m is able to disable all mobile phone frequencies CDMA GSM, 2G, 3G, 4G Lte, 4G Winamx ,Also is middle RF power drone jammer model, can defend 100% drones UAVs, like phantom 4, phantom 3 Professional, advanced, standard series, inspire series, block remote control signal 2.4, 5.8GHz, GPS L1 L2 L3 L4 L5, 433, RC 868 and 912MHz, jamming range 100-300 meters.

Basic specifications:
Jam signal type:
1:  mobile phone 3G/2G GSM CDMA DCS 4G LTE + WIFI-2.4G  signals
2:  mobile phone 3G/2G GSM CDMA DCS 4G LTE +GPSL1 signals
3:  Drone UAVS RC2.4G+RC5.8G+GPSL1L2L5+RC433 868 912 MHz
Output power: total 100W, 10-30W each band
Jam radius: 50-150 meters (GPS signal for 300m)
Power supply: 110-240V AC to 27V DC
Cooling system: high efficiency aluminum alloy radiator+ 5x cooling fans
Working time: not-stop working
Product size: 520x 340 x200mm
Product weight: approx 25kg (for panel directional antennas)
Package contents: jammer host x 1, antenna x6 or 6x 2 meter 1/2 cable for Omni-antennas .

Advantages:
★Output power total 100W, you can choose high gain 5-7dBi Omni or panel directional antennas, shielding 50-300m, still depends on the strength signal in given area
★Each unit can jam up to 6 frequency bands simultaneously, each frequency band is separate and with adjustable power from max to off (0), LED indicator lights display power supply
★100% safe VSWR over protection (isolator) for each modular
★Big aluminum alloy shell and cooling fans, not-stop to work
★Design for outdoor installation, secure design to avoid sabotage
★Additional option: wireless RC or Ethernet PC remote control
★100% Safe VSWR over protection for each modular


Key Technical specifications :
Channel Output Port Frequency range Average out-putting power
1 CDMA or GSM 851-894 or 925-960MHz 43dBm/20W
2 DCS/PCS 1805-1990MHz 40dBm/10W
3 3G 2110-2170MHz 40dBm/10W
4 4GLTE 700-803 or 790-862MHz 43dBm/20W
5 4G WIMAX 2500-2690 or 2300-2400MHz 40dBm/10W
6 WIFI 2.4G  2345-2500 MHz 40dBm/10W
Power supply: AC adapter 50 to 60Hz, (110 or 240V AC to 27V DC)
Dimensions: 520x340x 200mm
Packing size: 70*27*47cm
Net weight: 22kg
Gross weight: 25kg (use panel directional antennas)
Total power: 80W
Shielding radius: (50-150) meters at -75dBm
Still depends on the strength signal in given area
Shielding radius of VHF/UHF signal should be lesser than cell phone signal
Warranty: one year from delivery date
OMNI FRP antenna:
Dimensions: 500x 30x30mm
Net weight: 0.5kg
Gains: 5-10dBi VSWR >1.5
H: 180º
V: 20 º
Panel directional antenna:
Dimensions: 21x18x5cm
Net weight: 0.5kg
Gains: 5-10dBi VSWR >1.5
H: 60-90º
V: 20-30º
Basic station directional antenna:
Dimensions: 125x25x8.5cm
Net weight: 10kg
Gains: 12-20dBi VSWR >1.5
H: 60-90º
V: 20-30º

Key Technical specifications :
Channel Output Port Frequency range Average out-putting power
1 CDMA or GSM 851-894 or 925-960MHz 43dBm/20W
2 DCS/PCS 1805-1990MHz 40dBm/10W
3 3G 2110-2170MHz 40dBm/10W
4 4GLTE 700-803 or 790-862MHz 43dBm/20W
5 4G WIMAX 2500-2690 or 2300-2400MHz 40dBm/10W
6 GPSL1 1570-1610MHz 40dBm/10W
Power supply: AC adapter 50 to 60Hz, (110 or 240V AC to 27V DC)
Dimensions: 520x340x 200mm
Packing size: 70*27*47cm
Net weight: 22kg
Gross weight: 25kg (use panel directional antennas)
Total power: 80W
Shielding radius: (50-150) meters at -75dBm
Still depends on the strength signal in given area
Shielding radius of VHF/UHF signal should be lesser than cell phone signal
Warranty: one year from delivery date
OMNI FRP antenna:
Dimensions: 500x 30x30mm
Net weight: 0.5kg
Gains: 5-10dBi VSWR >1.5
H: 180º
V: 20 º
Panel directional antenna:
Dimensions: 21x18x5cm
Net weight: 0.5kg
Gains: 5-10dBi VSWR >1.5
H: 60-90º
V: 20-30º
Basic station directional antenna:
Dimensions: 125x25x8.5cm
Net weight: 10kg
Gains: 12-20dBi VSWR >1.5
H: 60-90º
V: 20-30º

Key Technical specifications :
Channel Output Port Frequency range Average out-putting power
1 RC2.4G 2400-2500MHz 44.5dbm /30W
2 RC 868 ,912 and 916 Or 433 868-916 or 433MHz 43dbm /20W
3 RC433 433 MHz 43dbm /20W
4 RC5.8G 5725-5850MHz 40dbm /10W
5 GPSL2+L5 1170-1280MHz 40dbm /10W
6 GPSL1 +GlonassL1 1560-1620 MHz 40dbm /10W
Power supply: AC adapter 50 to 60Hz, (110 or 240V AC to 27V DC)
Dimensions: 520x340x 200mm
Packing size: 70*27*47cm
Net weight: 22kg
Gross weight: 25kg (use panel directional antennas)
Total power: 100W
Shielding radius: (300-500) meters at -75dBm
Still depends on the strength signal in given area
Shielding radius of VHF/UHF signal should be lesser than cell phone signal
Warranty: one year from delivery date
OMNI FRP antenna:
Dimensions: 500x 30x30mm
Net weight: 0.5kg
Gains: 5-10dBi VSWR >1.5
H: 180º
V: 20 º
Panel directional antenna:
Dimensions: 21x18x5cm
Net weight: 0.5kg
Gains: 5-10dBi VSWR >1.5
H: 60-90º
V: 20-30º
Basic station directional antenna:
Dimensions: 125x25x8.5cm
Net weight: 10kg
Gains: 12-20dBi VSWR >1.5
H: 60-90º
V: 20-30º

OEM customized service:
Frequency range can be customized: 4GLTE Wimax, Wi-Fi 2.4G, 5.8G, 3.6GHz, GPSL1-L5
Silkscreen OEM service can be offered

Applications:
o Can be applied at meeting rooms, conference rooms, museums, galleries, theatres, concert halls, churches, temples, restaurants, classrooms, training centers, factories, banks, trains, bus, places that require silence, confidentiality and information security
o For some locations of special purpose such as hospitals, gas stations, do field test first to make sure no interference happened to the normal operation of their equipment and instrument
