| Key Technical specifications : | |||
| Channel | Output Port | Frequency range | Average out-putting power |
| 1 | CDMA or GSM | 850-894 or 95-960MHz | 44dBm/25W |
| 2 | PCS or DCS | 1920-1990 or 1805-1880MHz | 41dBm/15W |
| 3 | 3G | 2110-2170MHz | 41dBm/15W |
| 4 | 4G LTE 2600 | 2500-2690 or 2300-2400MHz | 40dBm/10W |
| 5 | 4G LTE 700 | 700-803 or 790-862MHz | 44dBm/25W |
| 6 | 4G1700 | 1710-1780MHz | 40dBm/10W |
| The below frequencies you can instead of above one to combined 6 bands | |||
| Option | Wi-Fi 5.2G | 5100-5500MHz | 40dBm/10W |
| Wi-Fi 5.8G | 5500-5580MHz | 40dBm/10W | |
| Wi-Fi 3.6G | 3500-3600MHz | 40dBm/10W | |
| Wi-Fi 2.4G | 2400-2500MHz | 40dBm/10W | |
| GPSL1 | 1570-1580MHz | 41dBm/15W | |
| GPSL2+L5 | 1170-1280MHz | 41dBm/15W | |
| LoJack and XM radio | 167-175MHz | 44dBm/25W | |
| VHF | 130-174MHz | 44dBm/25W | |
| UHF | 400-470MHz | 44dBm/25W | |
| UHF2 | 190-300MHz | 44dBm/25W | |
| UHF3 | 300-400MHz | 44dBm/25W | |
| Power supply: AC adapter 50 to 60Hz, (110 or 240V AC/27V DC) | |||
| Dimensions: 460 x 380 x 180 mm (not include antenna) | |||
| Packing size: 550 x450 x 300mm Net weight:15kg Gross weight: 15+3 antennas =18kg Working temperature: -30 to 60°C |
|||
| Total power: 75W Shielding radius: (50-100) meters at -75dBm Still depends on the strength signal in given area Shielding radius of VHF/UHF signal should be lesser than cell phone signal |
|||
| Warranty: one year from delivery date | |||
