2019 Newest 16 Antennas Handheld GPS Signal Jammer Cellular GSM 3G 4G 5GLTE WIFI Jammer/Blocker (EU &AU Version)

Item No.: JAM-N16-5G-EU
The latest unique design portable wireless signal Jammer with 16 antnnas to block all mobile phone 2G, 3G, 4G 5GLTE, Jamming LOJACK GPS, Wi-Fi 5G UHF/VHF signals too, Built-in big battery working 2+hours, Capacity and Woking Current &Volts LCD display.
Description

Product Description:
The latest unique design portable wireless signal Jammer with 16 antnnas to block all mobile phone 2G, 3G, 4G 5GLTE, Jamming LOJACK GPS, Wi-Fi 5G UHF/VHF signals too, Built-in big battery working 2+hours, Capacity and Woking Current &Volts LCD display.


Basic Specifications:
Jam Signal Type:Full Bands Mobile Phone 4G/3G/2G +WiFi2.4G/5GLTE+ GPSL1-L5 +UHF/VHF Walkie-Talkie+LOJACK+RC433 315 868
Output Power:Total 16W,1W each band
Jam Radius:10-20meters
Power Supply:AC110-240V to DC12V
Cooling System:High efficiency aluminum alloy radiator, Build-in 3x cooling fan
Working Time:Built-in battery:7.4V/12000mAh Continue working: more than 2.0+ hours
Product Size:280x130x46 mm(with hidden omni Antenna)
Product Weight: appr.2.0kg
Package Contents:Jammer Host x 1, AC Charger x1, omni antenna x16, Car Charger x1, External high gain antenna x16(option)

Advantages:

★The latest hidden antenna handheld design 16 bands all-in-one frequencies blocking all cell phone signals, LOJACK GPS, Wi-Fi, RF signals
★16 watt high output power, Jamming range 10 to 20 meters (at-75dBm, depends on signal strength in given area)
★Two sets different length antennas used in hidden or have better jamming effect
★Battery capacity LCD display (Capacity percentage, working Voltage/Current
★ABS Shell with good cooling system with cooling fans inside and bigger hot sink, temperature lower than 50℃
★With DIP switch, can turn on/off any signal band without affect other bands
★With car charger, 12V DC/AC power supply is also available
★With built-in bigger battery, can work more than (2.0+ hours) 120 minutes, Easily repeated charging.


Key Technical specifications : JAM-N16-5G-EU
Channel Output port Frequency range                        Average out-putting power
Band 1 RC912&GSM 912-960MHz 1 W
Band 2 DCS 1805-1880 MHz 1 W
Band 3 3G 2100-2170 MHz 1 W
Band 4 4G 800 758-826 MHZ 1 W
Band 5 4G 2600 2570-2690MHz 1 W
Band 6 RC 315 315 MHz 1 W
Band 7 4GLTE 1700 Or GPSL3L4 1700-1800 Or 1370-1390MHz 1 W
Band 8 5GLTE  3700-3600 MHZ 1 W
Band 9 5GLTE2  3600-4200 MHz 1 W
Band 10 WIFI2.4G&4G2300 2300-2500 MHz 1 W
Band 11 WIFI5.2G 5100-5500MHz 1 W
Band 12 WIFI5.8G 5500-5900MHz 1 W
Band 13 GPSL1 1570-1580MHz 1 W
Band 14 GPSL2+L5 1170-1280MHz 1 W
Band 15 VHF & LOJACK 135-174MHz 1 W
Band 16 UHF & RC 433&CDMA450 400-470 MHz 1 W
Power supply: adapter 50 to 60Hz AC (110-240V AC/12V DC)  Car Charger: DC12V IN
Dimensions: (length ,width, height) 280x130x46mm (include hidden antenna)
Lenth gof antenna :166mm   Gain:2.0dbi
Packing size: 330*250*80m     Net weight: 1.5kg               Gross weight: 2.0kg
Total power: 16W     Shielding radius: (10-20) meters at -75dBm Still depends on the strength signal in given area
Built-in battery:7.4V/12000mAh Continue working: more than 2.0+ hours
Warranty: one year from delivery date

OEM Customized service:
Silkscreen OEM service can be offered

Applications:
o    It can be applied at meeting rooms, conference rooms, museums, galleries, theatres, concert halls, churches, temples, restaurants, classrooms, training centers, factories, banks, trains, bus and morePlaces that require silence, confidentiality and information security
o    For some locations of special purpose such as hospitals, gas stations and more, please do field test first to make sure no interference happened to the normal operation of their equipment and instrument
