Product Description:
This is One of good quality and Low price middle power mobile phone jammer which are currently presented on the market with 6 bands and 70W output power this blocker is able to disable all cell phone frequencies CDMA GSM, 2, 3, 4G Wimax, 4G LTE, WIFI 2.4GHz or GPS or RC in the radius up to 80 meters.
Basic Specifications:
Jam Signal Type：
1: JAM-M6-W :Mobile phone 3G/2G GSM CDMA DCS 4GLTE +WIFI2.4G Signals
2: JAM-M6-G :Mobile phone 3G/2G GSM CDMA DCS 4GLTE +GPSL1 Signals
3.JAM-M6-UAV:Drone UAVS RC2.4G+RC5.8G+GPSL1L2L5+RC433 868 912 MHz
Advantages:
| Key Technical specifications : JAM-M6-W | |||
| Channel | Output Port | Frequency range | Average out-putting power |
| 1 | CDMA or GSM | 851-894 or 925-960MHz | 43dbm / 20W |
| 2 | DCS/PCS | 1805-1990MHz | 40dbm / 10W |
| 3 | 3G | 2110-2170MHz | 40dbm / 10W |
| 4 | 4GLTE | 700-803 or 790-862MHz | 43dbm / 20W |
| 5 | 4G WIMAX | 2500-2690 or 2300-2400MHz | 40dbm / 10W |
| 6 | WIFI2.4G | 2400-2500MHz | 40dbm / 10W |
| Power supply: AC adapter 50 to 60Hz, (110 or 240V AC-27V DC) | |||
| Dimensions: (length, width, height) 335x 238 x 60mm (not include antenna) | |||
| Package size: 450 x 235 x 95mm Net weight: 6kg Gross weight: 8kg Working temperature: -30 to 60°C |
|||
| Total power:80W Shielding radius: (20-80) meters At -75dBm Still depends on the strength signal in given area Shielding radius of VHF/UHF signal should be lesser than cell phone signal |
|||
| Warranty: one year from delivery date | |||
| Key Technical specifications : JAM-M6-G | |||
| Channel | Output Port | Frequency range | Average out-putting power |
| 1 | CDMA or GSM | 851-894 or 925-960MHz | 43dbm / 20W |
| 2 | DCS/PCS | 1805-1990MHz | 40dbm / 10W |
| 3 | 3G | 2110-2170MHz | 40dbm / 10W |
| 4 | 4GLTE | 700-803 or 790-862MHz | 43dbm / 20W |
| 5 | 4G WIMAX | 2500-2690 or 2300-2400MHz | 40dbm / 10W |
| 6 | GPSL1 | 1570-1610 MHz | 40dbm / 10W |
| Power supply: AC adapter 50 to 60Hz, (110 or 240V AC-27V DC) | |||
| Dimensions: (length, width, height) 335x 238 x 60mm (not include antenna) | |||
| Package size: 450 x 235 x 95mm Net weight: 6kg Gross weight: 8kg Working temperature: -30 to 60°C |
|||
| Total power:80W Shielding radius: (20-80) meters At -75dBm Still depends on the strength signal in given area Shielding radius of VHF/UHF signal should be lesser than cell phone signal |
|||
| Warranty: one year from delivery date | |||
| Key Technical specifications : JAM-M6-UAV | |||
| Channel | Output Port | Frequency range | Average out-putting power |
| 1 | RC2.4 G | 2400-2500 MHz | 40dBm/10W |
| 2 | RC 5.8G | 5725-5850MHz | 40dBm/10W |
| 3 | RC 433 | 433 MHz | 41.7dBm/15W |
| 4 | RC 868 ,912 and 916 Or 433 | 868-916 or 433MHz | 41.7dBm/15W |
| 5 | GPSL1+Glonassl1 | 1560-1620 MHz | 40dBm/10W |
| 6 | GPSL2 +L5+Glonassl2 | 1170-1280 MHz | 40dBm/10W |
| Power supply: AC adapter 50 to 60Hz, (110 or 240V AC-27V DC) | |||
| Dimensions: (length, width, height) 335x 238 x 60mm (not include antenna) | |||
| Package size: 450 x 235 x 95mm Net weight: 6kg Gross weight: 8kg Working temperature: -30 to 60°C |
|||
| Total power:70W Shielding radius: (20-80) meters At -75dBm Still depends on the strength signal in given area Shielding radius of VHF/UHF signal should be lesser than cell phone signal |
|||
| Warranty: one year from delivery date | |||
