Backpack Drone Jammer with High Power,6-band WiFi GPS up to 500m/Built-in Battery/UAV Signal Jammer

Item No.: 1704P6-UAV
Backpack Drone Jammer with High Power, 6-band WiFi GPS up to 500m/Built-in Battery/UAV Signal Jammer,Middle RF power, Cover 100% drones UAVs, like Phantom 4, Phantom 3 Professional, advanced, standard series, inspire series ,Directional jamming range: 50-
Description
Product description:
Backpack Drone Jammer with High Power, 6-band WiFi GPS up to 500m/Built-in Battery/UAV Signal Jammer,Middle RF power, Cover 100% drones UAVs, like Phantom 4, Phantom 3 Professional, advanced, standard series, inspire series ,Directional jamming range: 50-500 meters,6-band in one directional antenna ,Built-in battery +24V/20Ah LiFePO4 can work 1 hour.

Basic specifications:
Jam signal type:Drone UAVS RC2.4G+RC5.8G+GPSL1L2L5+RC433 868 912 MHz
Output power:Total 70W, 10-15W each band
Jam radius:100-500 meters
Power supply:AC110-240V to DC27V
Cooling system:High efficiency aluminum alloy radiator+ 2X cooling fans
Working time:Not-stop Working(Build-in AC power DC27V and Battery 27V20Ah working 1.5hours)
Product size: 400 x 290 x 135mm (not Include Antenna)
Product weight: appr.20kg (for OMNI antennas)
Package contents:Jammer Host x 1, Battery Charge x 1, antenna x6, Manpack bag x1

Advantage:
★10-15W each band, 6 bands/antennas
★Built-in battery, operating time more than 60 minutes (more option about battery working time)
★Battery power and charger display via LED screen
★Stand-alone modular design and individual power control
★Adjustable output power each band/channel
★VSWR over protection for each modular
★Designed to cut off down-link only, therefore it does not have interference to base station and repeater
★Professional manpack design, army use to jam the RC bomb or drone.

Key Technical specifications :
Channel Output Port Frequency range Average out-putting power
1 GPS/glonass L1+B1 1560-1620MHz 40dBm/10W
2 GPSL2+L5+B2B3 1170-1280MHz 40dBm / 10W
3 RC433 2110-2170MHz 41dBm / 15W
4 RC868 OR 912 868-812MHz 41dBm / 15W
5 RC2.4G 2400-2500MHz 40dBm / 10W
6 RC5.8G 5725-5850MHz 40dBm / 10W
Power supply: AC adapter 50 to 60Hz,   (110 AC or 240-C27V DC)
Dimensions:  400 x 290 x 135 mm (not include antenna)
Package size: 550 x450 x 300mm
Net weight:16kg
Gross weight:15 + 3kg antennas-20kg
Working temperature: -30 to 60C
Total power:70W
Shielding radius: 100-500 meters at -75dBm
Still depends on the strength signal in given area
Shielding radius of VHF/UHF signal should be lesser than cell phone signal
Warranty: one year from delivery date

Package contents:
1 piece manpack/backpack jammer
1 piece manpack bag
1 piece 110 AC or 220V DC/12 or 27V power charger
6-piece antennas Omni 500mm long

OEM customized services:
All 6 frequency modules we can mix very flexible
Options: remote/alarm control 315, 433, 920-965MHz, GPS L1/L2/L3/L4/L5, LoJack 173MHz, 4G 700-800MHz (USA), UHF, VHF, SAT Satellite Phones 1520-1670MHz,Any combinations and customizations are possible, just send us your inquiry and we will give you our recommendation

Applications:
Factory, prison, government, airport, VIP protection, convoys protection, military forces, SWAT teams, anti-drug units, riot-control units and embassies protection
