★Output power total 300w, You can choose high gain 5-10 dbi OMNI or Panel directional antennas, shielding 200-1500m,Still depends on the strength signal in given area.
★Each module is designed with five indication lights, to show Power, Run and Alarm (Perfect VSWR Alarm System, fully protected circuit in case of disconnection of antennas)
★Each unit can jam up to 6 frequency bands simultaneously, each frequency band is separate and with adjustable power from max to off (0)
★100% safe VSWR over protection (isolator) for each modular
★Big aluminum alloy shell and 20 pieces cooling fans, not-stop to work
★with Pelican case 1620 ,carry out .
★Build-in Battery 27V56Ah continue working 1.5hours, Battery Power and charger stative display via LED screen
★Selection of antennas to provide more flexibility regarding jamming coverage.
| Key Technical specifications : | |||
| Channel | Output Port | Frequency range | Average out-putting power |
| 1 | RC2.4G | 2400-2500MHz | 50dbm/100W |
| 2 | RC5.8G | 5725-5850MHz | 45dbm/30W |
| 3 | RC433 or 314 | 433 or 315MHz | 45dbm/30W |
| 4 | RC868/912 and 915 | 868-915MHz | 47dbm/50W |
| 5 | GPSL1/Glonass | 1560-1620MHz | 47dbm/50W |
| 6 | GPSL2+L5 | 1170-1280MHz | 47dbm/50W |
| Power supply: AC adapter 50 to 60Hz, (110 or 240V AC/27V DC) Battery: 27V/56Ah |
|||
| Dimensions: 630*500*350mm (not include antenna) | |||
| Packing size: 800 x 700 x 600mm Net weight: 50kg Gross weight: 50kg + 6kg antennas=56kg Working temperature: -30 to 60°C |
|||
| Total power: 300W Shielding radius: (500-1500) meters at -75dBm Still depends on the strength signal in given area Shielding radius of VHF/UHF signal should be lesser than cell phone signal |
|||
| Warranty: one year from delivery date | |||
Features:
Cover 100% drones UAVs
Pelican 1620 case raining-proof
Jamming range radius: 500-1500 meters
Built-in battery can works 1.5 hours
Packing contents:
1 piece desktop jammer
1 piece 110 or 220V AC/12 or 27V DC/20A power supplier
8-piece antennas omni 500mm long
Additional options:
- Directional external patch panel antennas
- Omni car magnetic antenna bases
OEM Customized Service:
Frequency Range can be customized: 4GLTE Wimax, Wi-Fi 2.4G,5.8G,3.6GHz, GPSL1-L5 and more
Silkscreen OEM service can be offered.
Application:
1) Protection of prohibited areas, such as: prison, military management area, national strategic resources projects, nuclear industry facilities, airports, political regions and etc;
2) To prevent the leakage of information on the scene, such as: major criminal cases on-site, urban management law enforcement scene, an important security venues, political followers protection, large-scale performance rehearsal, archaeological excavation site, large groups event site;
3) To combat the use of unmanned aerial vehicles as a carrier of illegal activities, such as: transport / drug trafficking, smuggling, illegal goods or information transmission.
