Key Technical specifications : | |||
Channel | Output Port | Frequency range | Average out-putting power |
1 | RC2.4G | 2400-2500MHz | 40dBm/10W |
2 | RC868, 912 and 916 or 433 | 868-916 or 433MHz | 43dBm/20W |
3 | RC433 | 433MHz | 41.7dBm/15W |
4 | RC5.8G | 5725-5850MHz | 40dBm/10W |
5 | GPSL1 and GLONASS L1 | 1560-1620MHz | 40dBm/10W |
6 | GPSL2+L5 | 1170-1280MHz | 40dBm/10W |
Power supply: AC adapter 50 to 60Hz, (110 or 240V AC-27V DC) Battery: 27V/20Ah |
|||
Dimensions: 460 x 380 x 180mm (not include antenna) | |||
Package size: 550 x 500 x 300mm Net weight: 18kg Gross weight: 18kg + 6kg antennas=22kg Working temperature: -30 to 60℃ |
|||
Total power: 75W Shielding radius: (50-300) meters at -75dBm Still depends on the strength signal in given area Shielding radius of VHF/UHF signal should be lesser than cell phone signal |
|||
Warranty: one year from delivery date | |||
OMNI FRP antenna: Dimensions: 500x 30 x 30mm Net weight: 0.5kg Gains: 5-10dBi VSWR >1.5 H: 180º V: 20 º |
|||
Panel directional antenna: Dimensions: 21x 18 x 5cm Net weight: 0.5kg Gains: 5-10dBi VSWR >1.5 H: 60-90º V: 20-30º |
