Key Technical specifications : JAM-D4-UAV | |||
Channel | Output Port | Frequency range | Average out-putting power |
1 | RC2.4G | 2400-2500MHz | 40dbm/10W |
2 | RC5.8G | 5725-5850MHz | 36dbm/4W |
3 | GPSL1 and Glonass L1 | 1560-1620MHz | 37dbm/5W |
4 | GPSL2+L5 | 1170-1280MHz | 37dbm/5W |
Power supply: AC adapter 50 to 60Hz, (AC110 or 240V-DC24V) Build-in battery: 24V5Ah Working Time:1.5Hours |
|||
Dimension: (length, width, height ) 380*260*95mm | |||
Package Size: 450 x 350 x 300mm N.W:3.5kg G.W:6kg | |||
Total Power:24W Shielding Radius: (100-500meters) Still depends on the strength signal in given area. |
|||
Warranty: one year from delivery date |
