Advantages:
Key technical specifications: JAM-P16 | |||
Channel | Output port | Frequency range | Average out-putting power |
Band 1 | VHF&LOJACK | 135-175MHz | 30±1dBm/ 1±0.2W |
Band 2 | 4G700 or 800 | 700-805 or 758-821MHz | 30±1dBm/ 1±0.2W |
Band 3 | 4G1700or GPSL3L4 | 1710-1780 or 1370-1390MHz | 30±1dBm/ 1±0.2W |
Band 4 | 3G | 2110-2170MHZ | 30±1dBm/ 1±0.2W |
Band 5 | WIFI5.2G | 5125-5350MHz | 30±1dBm/ 1±0.2W |
Band 6 | GPSL2L5 | 1170-1280MHz | 30±1dBm/ 1±0.2W |
Band 7 | CDMA&868 | 850-894MHz | 30±1dBm/ 1±0.2W |
Band 8 | 4G2600 or 4G2300 | 2500-2690 or 2300-2400MHZ | 30±1dBm/ 1±0.2W |
Band 9 | RC315 | 315MHz | 30±1dBm/ 1±0.2W |
Band 10 | RC433 | 433MHz | 30±1dBm/ 1±0.2W |
Band 11 | UHF&CDMA450 | 400-470MHz | 30±1dBm/ 1±0.2W |
Band 12 | GSM&LORA | 925-960MHz | 30±1dBm/ 1±0.2W |
Band 13 | GPSL1 | 1570-1580MHz | 30±1dBm/ 1±0.2W |
Band 14 | WIFI2.4G | 2400-2500MHz | 30±1dBm/ 1±0.2W |
Band 15 | DCS/PCS | 1805-1880/1920-1990MHz | 30±1dBm/ 1±0.2W |
Band 16 | WIFI5.8G | 5725-5850MHz | 30±1dBm/ 1±0.2W |
Power supply: adapter 50 to 60Hz AC (110-240V AC/12V DC) Car Charger: DC12V IN | |||
Dimensions: (length ,width, height) 190x126x46mm (without antenna) Length of antenna :166mm Gain:2.0dbi |
|||
Packing size:330*250*80mm Net weight: 1.5kg Gross weight: 2.0kg | |||
Total power: 16W Shielding radius: (2-25) meters at -75dBm Still depends on the strength signal in given area Built-in battery:7.4V/12000mAh Continue working: more than 2.5+ hours |
|||
Warranty: one year from delivery date |
